The form diamond roller is used for dressing grinding wheels ( vitrified cbn grinding wheel, conventional grinding wheel). Used for Automobile engine, machinery industry, robot parts, flute dresser, turbine blade, automobile valves, crankshafts, sewing industry, turbine blade – fir tree root form, cam Grinding, bearing industry, ball joints, needle injectors
1. High production efficiency, long service life and low cost of dressing of individual parts. 2. It can maintain the stability of parts precision and the high qualified rate of products for a long time. 3.For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results. 4. Easy to operate. 5. High utilization of CNC machine , easy to achieve automation and mass production.
high precision diamond rotary grinding wheel for the desired grinding application. Also available are CNC dressing wheels with PCD or natural diamonds and gear grinding wheels or custom-built diamond tools for grinding of CBN wheels.
The ordinary ceramic grinding wheel or CBN grinding wheel is trimmed by the rotary profile dresser installed on the grinder, and the part is ground after the grinding wheel is formed, there by copying the contour, accuracy and size of the rotary profile dresser to the processed part through the grinding wheel surface.
Diamond dressing rolls (rotary dresser) is a kind of diamond roller tools for dressing grinding wheel that a working surface with much small grain diamond. Diamond dressing rolls used for inner-surface grinders with vitrified CBN wheels, angular grinders, cylindrical grinders, centerless grinders and surface grinders.
More Superhard Diamond rotary grinding wheel consists of a rectangular artificial diamonds arranged and sintered in a cylindrical shape, making this a traverse rotary dresser with unusually high dressing frequency reproducibility.
The diamond dressing tools are a new type of grinding wheel dressing tool that our company uses fine-grained natural diamonds arranged in special alloy powder according to requirements and formed and sintered. It has its own unique features in the use of grinding machines for dressing some special current grinding wheels.
Form diamond roller dressing grinding wheel ( profile / form dressing)
Applications: Ball and roller bearings,linear guides, ball screws, gear teeth or racks, turbine industry for grinding the blades,the automotive and -supply industry, general mechanical engineering, etc
High utilization of CNC machine , easy to achieve automation and mass production.
The high precision rotary diamond dresser is used for dressing grinding wheels ( vitrified cbn grinding wheel, conventional grinding wheel).
• Reduction of dressing costs per workpiece • Optimized utilization of machine capacity • Automation of the dressing process • Repeatable high precision with low workpiece rejects • Rapid incorporation of complex profiles in the grinding wheel
The rotary diamond dresser dressing grinding wheel is an efficient shaping wheel dressing tool, especially used for the dressing of complex or high-precision shaping surfaces. Now it is made by two processes: electroforming and sintering.
Diamond rotary dresser is a type of the rotary dresser. This is a diamond dresser for gear forming of worm-like general grinding wheels. High precision ddiamond rotary dresser for the desired grinding application. Also available are CNC dressing wheels with PCD or natural diamonds and gear grinding wheels or custom-built diamond tools for grinding of CBN wheels.
Manufacturing precision requirements for electroplated diamond dressing roller Runout: 0.002mm Straightness: 0.002-0.005mm Roundness: 0.002-0.005mm Tolerance range of length and step difference: L±0.002-0.005mm Radius dimension tolerance range: R±0.002-0.005ram Angle tolerance range: A±1
High precision Electroplated Diamond Dressing Rollers are now recognized as the most efficient and economic means of dressing and truing grinding wheels to the correct form, tolerance and condition. Electroplated Diamond Dressing Roller is growing rapidly in the manufacture of components for automotive, aerospace, power generation, machine tool and precision engineering industries.
High-precision electroplated diamond dressing roller (abbreviated as diamond rollers or rollers) are high-efficiency, long-life, and low-cost grinding wheel dressing tools used for mass forming and grinding of special machine tools and gear grinders.
High precision rotary dresser and form dressing roll. Used for dressing grinding wheel (vitrified cbn wheel, SG grinding wheel) on Automotive industry and Gear industry.
It’s important to select a rotary profile dresser that is the proper shape, size, and quality for your grinding wheel. We offer rotary diamond dressers that are reverse plated, handset sintered, CDV sintered, or random set sintered — as well as single-point, stationary, and multi-point dressers.
Roller diamond dresser manufacturing methods include: hand sintering method, random arrangement sintering method, electroforming method, etc. Diamond roller dressers are used in: bearings, auto parts, textile machinery, aerospace and other industries
Usually diamond rotary dressercorresponds precisely to that of the workpiece but it can also be adapted to the specific grinding. Shorter dressing time and long tool life leads to high productivity and consistent process conditions. Many kinds of conventional grinding wheels, and in special cases super-hard grinding wheels, can be dressed with this dressing method.
1. High production efficiency, long service life and low cost of dressing of individual parts. 2. It can maintain the stability of parts precision and the high qualified rate of products for a long time. 3. For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results. 4. Easy to operate. 5. High utilization of CNC machine , easy to achieve automation and mass production.
rotary diamond dresser dressing vitrified cbn wheel is used for inner-surface grinders with vitrified CBN wheels, angular grinders, cylindrical grinders, centerless grinders and surface grinders.
Multi-point diamond dresser – This tool has many small diamonds embedded into the diamond section. This tool is only good for straight or taper dressing—it can’t be used for dressing a form into the wheel.
Diamond dressing tools mainly include diamond pens, diamond blades, diamond rollers and diamond abrasive belts.
