Grinding Solution

Last week, Moresuperhard participated in the 2nd conference on ceramic technology for semiconductor industry.

We are committed to improving the quality of our products and services to provide customers with better grinding results and value!
Email: [email protected]
Whatsapp: 8615838271917

► Edge wheel for silicon and sapphire wafer edge grinding. A small diameter wheel is used for notch grinding
► Metal diamond wheel for rough grinding to get an accurate edge profile
► Resin diamond wheel for finish grinding to get good surface roughness

Best suited for demanding applications where a harder-wearing, longer-lasting blade is required.
specifications can be made according to customers requirements

Moresuperhard provides qualified services For DANOBAT’s Precision Grinding Machines.
External grinding models：CG, PG, LG, HG, WT, mBTG-DANTIP,
Internal grinding models: ID, IRD,ILD, IED.

► Vitrified diamond/CBN grinding wheels
► Resind diamond/CBN grinding wheels
► Conventional grinding wheels
► Diamond dressing wheels

Silicon wafer back grinding, resin/vitrified/metal bond diamond wheels are used for back thinning, grinding and fine grinding of apphire epitaxial wafer, silicon wafer, gallium arsenide and GaN wafer

Silicon wafer back grinding, resin/vitrified bond diamond wheels are used for back thinning, grinding and fine grinding of apphire epitaxial wafer, silicon wafer, gallium arsenide and GaN wafer

What Types of internal grinding wheels do we have?
* vitrified CBN internal grinding wheel
* resin diamond & CBN internal wheel
* electroplated diamond mounted points
* abrasive internal grinding wheel

► Polishing and finishing of glass, LCD/LED substrates, precision optics, hard disk, metal and semiconductor wafer surfaces
► Model: MSH-66, MSH-77, MSH-13, MSH-LASER, MSH-46
► Thickness: 0.02″ (0.508 mm) – 0.20″ (5.08 mm)

Moresuperhard provides customized resin or electroplated diamond belts. There are many grinding advantages such as sharpness, durability, flexibility, and dry or wet grinding for diamond sanding abrasive belts with various patterns. Please choose different design patterns according to your needs.

Moresuperhard high-precision electroplating CBN grinding rod (JG coordinate grinding rod) is equipped with imported continuous orbital CNC coordinate grinding machine (such as Moore Moore, Hauser Hauser, Mitsuiseiki Mitsui, Waida and Ida, etc.) to process fine molds, in the production of motor molds, leads Structural molds, semiconductor special molding molds and other fields are widely used. Products can be customized for special types according to customer requirements, such as roughing, finishing, polishing and other special requirements can be satisfied.

CNC coordinate grinder is used to process continuous dies of electronic components, fine punching dies, scoring dies and engineering plastic dies of camera and watch parts.

How many types of coordinate grinding are there? (Coordinate grinder)

High precision Jig grinding wheels matching imported continuous track CNC coordinate grinding machine. Such as Moore, Hauser, Mitsuiseiki, Waida and etc.)
Applications of Jig grinding wheels
Processing precision molds, in the manufacture of motor molds, lead frame molds, semiconductor molding molds and other fields are widely used. Products can be customized according to customer requirements, such as rough machining, finishing, polishing and other special requirements can be met. Abrasive diamond and CBN are optional. Diamond grinding objects are hard alloy (tungsten steel), ceramics, etc. CBN grinds high speed steel and heat treated steel pieces.

CBN for I.D. and Jig Grinding of High Speed Steels and Alloys
Diamond for I.D. and Jig Grinding of Carbides and Non-Metallics

JIG mounted points grinding wheels are used for precision made and for this precise craft. JIG grinding can be performed on many materials, including steels (hard and soft), stainless steel, non-ferrous materials, cast-iron, glass, ceramics, plastics, rubber and fiber optics.
– Use for plastics, cast iron, glass, other non-metallic materials & non-ferrous metals
– Use for stainless & construction steels
– Use for steels for tool & die
– Use for harder stainless steels & hardened steels

Application: single-stroke honing technology has been adopted in automobile, tractor, power machinery, construction machinery, refrigeration machinery and aerospace industry.
Hinge honing has the advantages of high efficiency, good surface quality and high dimensional consistency.

Single stroke honing tools: electroplated diamond honing reamer and sintered honing reamer
Vertical single stroke honing machines: Sunnen, Engis, Nagel, Belden, etc

Application areas of diamond honing reamer
Hydraulic valves and valve bodies, distribution valves, Gears, ABS, brake cylinder, supercharger, rocker arms, connecting rod, parking pawls, crankcase, sprockets, powdered metal components, ceramic components.

Single stroke honing (Expansion reamers) process means that the honing head slowly enters the hole of the workpiece under high speed rotation, and then slowly exits the hole at the same speed. Through the cycle of “one in”, “one out”, hole honing is completed.

Single stroke honing tools, single pass honing reamer (Expansion reamers)
Single-pass honing tools: electroplated diamond honing reamer and sintered honing reamer
Vertical single pass honing machines: Sunnen, Engis, Nagel, Belden, etc

Vitrified & resin hybrid CBN rail grinding wheel
-High grinding efficiency
-Long service life
-Little wear
-Low dust concentration
-High thermal conductivity(extend the service life of the rail by 20-30%)

Diamond Polishing Paste is divided into water-soluble polishing paste and oil-soluble polishing paste
Package of polishing paste: injector, bag or box
Spect: 5g、10g、30g、100g and so on
Diamond size of polishing pase: W0.25 W0.5 W1 W1.5 W2.5 W3.5 W5 W7 W10 W14 W20 W28 W40
Moresuperhard can also provide various of grain size diamond polishing paste according to users’ requirement and we can also provide CBN polishing paste

Moresuperhard can also provide various grain size diamond polishing compound according to users’ requirement and we can also provide CBN polishing compound

Diamond polishing compound for polishing
Grinding and polishing of precision ceramics, magnetic materials, magnetic heads, iron hydrochloride, cemented carbide
Fine grinding of metallographic and petrographic samples of high-hardness materials, etc.
Precision medical equipment, dental materials (dentures) grinding and polishing
Diamond polishing compound has better lubrication and cooling performance, high grinding efficiency, good surface processing quality, better finish, easy to use, etc.

Diamond polishing paste, diamond compound is a kind of material for polishing and lapping, which consists of diamond micro powder and corresponding grinding aids.
Diamond polishing paste for Fine grinding of metallographic and petrographic samples of high-hardness materials, etc.

Diamond polishing paste
-Polishing of metal workpieces (such as measuring tools, cutting tools, knives, molds, etc.)
-Grinding and polishing of tungsten steel molds, optical molds, injection molds, etc.
-Grinding and polishing of jewelry, jade, gems and agate crafts
-Optical lenses, crystals, wafers, integrated circuits, quartz wafers, monocrystalline silicon wafers, sapphire, semiconductors
-Grinding and polishing of precision ceramics, magnetic materials, magnetic heads, iron hydrochloride, cemented carbide
-Fine grinding of metallographic and petrographic samples of high-hardness materials, etc.
-Precision medical equipment, dental materials (dentures) grinding and polishing

Diamond polishing paste, diamond compound has better lubrication and cooling performance, high grinding efficiency, good surface processing quality, better finish, easy to use, etc.
Diamond suspension and Paste are high quality diamond polishing products that provide repeatable performance and deliver exceptional surface quality.

Diamond polishing paste is a kind of material for polishing and lapping, which consists of diamond micro powder and corresponding grinding aids.
High precision diamond polishing paste is used for
Polishing of metal workpieces (such as measuring tools, cutting tools, knives, molds, etc.)
-Grinding and polishing of tungsten steel molds, optical molds, injection molds, etc.
-Grinding and polishing of jewelry, jade, gems and agate crafts

Diamond Polishing Paste, Diamond Compound is divided into water-soluble polishing paste and oil-soluble polishing paste
Package: injector, bag or box
Spect: 5g、10g、30g、100g and so on
Diamond size of polishing pase: W0.25 W0.5 W1 W1.5 W2.5 W3.5 W5 W7 W10 W14 W20 W28 W40
Moresuperhard can also provide special products according to users’ requirement and we can also provide CBN polishing paste, CBN compound
