Diamond dressers for grinding wheels in New energy vehicle motor shafts

Moresuperhard provides qualified services For DANOBAT’s Precision Grinding Machines.
External grinding models：CG, PG, LG, HG, WT, mBTG-DANTIP,
Internal grinding models: ID, IRD,ILD, IED.

► Vitrified diamond/CBN grinding wheels
► Resind diamond/CBN grinding wheels
► Conventional grinding wheels
► Diamond dressing wheels

Grinding machine information: The customer mainly makes compressor parts and has LAPMASTER and 20 Speedfam double-end grinding machines.
Processing method: before the polished way more, now consider switching to the grinding way.
Processing details: The compressor valve plate is 420 stainless steel, most of the low carbon steel and bearing steel on the market are more, and there are no successful cases of stainless steel grinding.
Feedback: The rough grinding with diamond double-end grinding discs is very efficient, and the fine grinding with CBN double-end grinding discs is very good in terms of finish.

► Model: 1A1, 1V1, 14A1, 3A1
► Application: fluting end mill, drill, cutter
► Advantages of flute wheel
* Online truing & dressing capability lower tooling cost
* Better edge quality

More SuperHard provides a line of solution and services for ultra performance cnc cutting tools grinding on CNC machines. Our services include fluting, gashing clear edge and relief angle, OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable cnc machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

► Application: grinding carbide and HSS. (such as drill, end mill, reamer)
► A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
► Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc

Resin bond diamond grinding wheels for grinding digital controlled cutting tools (such as tungsten carbide, HSS, milling cutter, reamer and drill)
Perfect processing quality
High efficient grinding with fast feeding
Good wear resistance and shape keeping

► Grinding, regrind pcd, pcbn, cvd tools
► Bonded: vitrified bond, resin bond, metal bond
► Width: 1mm – 20mm

► Up to #10000 for super finish
► Cutting-edge chipping <5 μm ► Provide dressing wheel to dress PCD grinding wheel

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with a vitrified grinding wheel the effect is more outstanding.
Many breakthroughs have been made in PCD composite material, CBN composite material and tungsten carbide processing, thus the application range of grinding wheels is wider.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

We are committed to improving the quality of our products and services to provide customers with better grinding results and value!
Email: [email protected]
Whatsapp: 8615838271917

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

Film belt is for grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum-magnesium alloy, aluminum beryllium alloy, titanium alloy and etc. hard brittle materials.

Moresuperhard can offer high-quality diamond internal grinding wheels (PA, SG), CBN internal grinding wheel, and diamond internal grinding wheels for hydraulic tappets/hydraulic valve lifters grinding.

Details about Moresuperhard’s internal grinding wheels:

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor .
► Body type: ID Wheel with Shank, ID Wheel without Shank
► Model type: 1A8, 1A1W, 1A1, DWA

The bond strength of this type of diamond grinding wheel is weaker than that of other wheels. The self-sharpening for carbide saw blade is better, no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on

What Types of internal grinding wheels do we have?
* vitrified CBN internal grinding wheel
* resin diamond & CBN internal wheel
* electroplated diamond mounted points
* abrasive internal grinding wheel

1. High production efficiency, long service life and low cost of dressing of individual parts.
2. It can maintain the stability of parts precision and the high qualified rate of products for a long time.
3. For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results.
4. Easy to operate.
5. High utilization of CNC machine, easy to achieve automation and mass production.

►Diamond coated head. Wear-resistant, close to the sand surface, not easy to fall off, maintains sharpness, long wear.
►Its surface can be cleaned and restored to regain its original shape by using a dressing stone.

►Can be installed on the electronic grinder, hanging mill and hand electric drill (not included here).
►Used for sculpturing, dressing, precision grinding and internal grinding carbide in ceramic, glass, precious stone, alloy and many other abrasive materials.
►Adding water when using the Diamond grinding head is good, can improve the sharpness and the life of the grinding needle.

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor .
► Body type: ID Wheel with Shank, ID Wheel without Shank
► Model type: 1A8, 1A1W, 1A1, DWA
► We can offer: abrasive internal grinding wheel (PA, SG), CBN internal grinding wheel, Diamond internal grinding wh

Moresuperhard provides a line of solution and services for ultra performance cnc tools grinding on CNC machines.
Fluting, gashing, OD grinding tungsten carbide, HSS, milling cutter, reamer and drill, etc
Applicable cnc machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

► Steady drilling with better smoothness
► Free drilling and long lifespan
► No damage to the edge
► High drilling efficiency

►High Precision Centerless Grinding Machines Models:
-FX12S
-FX18S/AS/BS
-FX18HS(Static Pressure Spindle)
-FX20S

►Broad Applications:
-Automotive Industry: shafts, pins, valves, and bearings
-Aerospace Industry: turbine shafts, landing gear components, and fuel system parts
-Medical Industry
-Tool and Die Industry
-Bearings industry
-Tool and Die Industry: cutting tools, punches, and dies with high accuracy and surface quality

High Precision with High Rigidity Body Structure

► OD cylindrical grinding wheel (1A1 shape)
► Diamond sanding belts
► Diamond internal grinding wheel
► Diamond honing stone
Model: 1A1 diamond wheel (diameter up to 1100mm)

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

The diamond resin grinding wheel has a good polishing effect. The grinding wheel is sharp and not easy to be blocked during grinding.
The specific characteristics are as follows:
1. The grinding efficiency is high, and the grinding wheel consumption is relatively slow;
2. Good self-sharpening, low heat generation during grinding, not easy to block, reducing the phenomenon of work burns during grinding;
3. The grinding wheel has a certain elasticity, which is conducive to improving the roughness of the workpiece surface. It is mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes;
4. The diamond resin grinding wheel is cured at low temperature, the production cycle is short, and the equipment and supply process is relatively simple; due to the fluidity of the resin, it is easy to form a grinding wheel with complex surfaces

Peripheral Diamond Grinding wheels are used for indexable inserts grinding.
Peripheral Grinding tungsten carbide inserts, ceramic inserts, cermet, pcd and cbn inserts
Model: 6A2T, 6A2M, 11A2B, 12A2T
Bonded: resin bond and vitrified bond
