CBN Wheel Diamond Resin Wheels For Glass

1. High production efficiency, long service life and low cost of dressing of individual parts.
2. It can maintain the stability of parts precision and the high qualified rate of products for a long time.
3.For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results.
4. Easy to operate.
5. High utilization of CNC machine , easy to achieve automation and mass production.

► Application: grinding carbide and HSS. (such as drill, end mill, reamer)
► A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
► Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc
Metal bond diamond wheels for grinding tungsten carbide and HSS steel. Such as drills, end mills, reamers, micro drills, mini end mills and burrs, etc
Suitable CNC Grinding Machine: ANCA,WALTER,SCHUTTE,EWAG,SCHNEEBERGER,HUFFMANN and so on.

The diamond resin grinding wheel has a good polishing effect. The grinding wheel is sharp and not easy to be blocked during grinding.
The specific characteristics are as follows:
1. The grinding efficiency is high, and the grinding wheel consumption is relatively slow;
2. Good self-sharpening, low heat generation during grinding, not easy to block, reducing the phenomenon of work burns during grinding;
3. The grinding wheel has a certain elasticity, which is conducive to improving the roughness of the workpiece surface. It is mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes;
4. The diamond resin grinding wheel is cured at low temperature, the production cycle is short, and the equipment and supply process is relatively simple; due to the fluidity of the resin, it is easy to form a grinding wheel with complex surfaces

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Electroplated grinding wheels is an excellent option when an aggressive amount of stock removal is required.

A single, uniform layer of diamond or CBN crystal is electroplated to a precision machined steel surface.

Cylindrical Grinder Accessories
– Precision Spindle
– V and flat guide rail
– C3 Ball Screw
– Precision hand shovel
– Roller grinding wheel corrector

Conventional cylindrical grinding machine is designed for the grinding of workpieces in single-component or small series production runs. Cylindrical grinder is suitable for use in any industry where precise small components are manufactured.

Moresuperhard has upgraded the grinding products including grinding wheels and grinding dressers that can perfectly match the DANOBAT’s grinding machine for workpiece grinding, in order to meet the grinding needs of customers who use a specific DANOBAT grinding machine.

► Grinding Indexable inserts (tungsten carbide inserts, ceramic inserts, CBN inserts)
► Model: 6A2T, 6A2M, 11A2B, 12A2T
► Grinding Machine: WENDT, WAIDA, AGATHON, EWAG, COBORN, etc.

Applications of diamond glass saw blade: cutting different types of glass (such as glass mosaic, sheet glass, crystallized glass, glass tile, coated glass, etc)
Size of glass cutting blades: 4″- 16″
►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use

Metal bonded diamond wheels are best suited for edge rough grinding and have coarser diamonds for higher material removal. The diamonds are embedded in a sintered metal matrix. These wheels can either have a segmented pattern for edge rough grinding or a continuous pattern for fine grinding.
Features:
Wear resistant with a longer service life
The higher material removal rate
High grinding efficiency

Diamond Polishing Paste, Diamond Compound is divided into a water-soluble polishing paste and an oil-soluble polishing paste.

Moresuperhard has been found on the determination to make a conspicuous commitment to serve high quality of diamond grinding wheels for tungsten carbide. diamond grinding wheels for tungsten carbide have been specifically developed to meet the demanding needs of precision cutting tool manufactures as well as re-sharpeners.

The feed rate of the grinding resin grinding wheel of the more superhard five-axis milling cutter can reach 100-120MM/M, and the cutting depth is 3-4.5MM at a time.
5 axis cnc grinding wheels has the characteristics of high efficiency and good durability.
The ground tool is not only smooth and clean. Good, and suitable for all kinds of machine tools, and can replace imported similar products.

The self-sharpening for carbide saw blade is better, no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on

Vitrified CBN internal grinding wheels are made of cubic boron nitride abrasives and sintered with metal powder, resin powder and ceramic as a bonding agent to form various shapes of abrasives for industrial grinding, polishing and lapping.

1. Vacuum brazing technology can realize the chemical metallurgical combination of diamond, bonding agent (brazing alloy material) and metal matrix interface, with high bonding strength.
2. Because of the high bond strength at the interface, only a very thin bond thickness is sufficient to hold the abrasive firmly, and its exposed height can reach 70% to 80%, making fuller use of the abrasive and greatly improving the tool life and machining efficiency.
3. Compared with the traditional technology, the maximum allowable edge value of diamond tools can be increased by more than 50%, and the diamond consumption of workpiece material per unit volume is reduced by more than half without increasing or decreasing the power consumption of tools.
Vacuum brazed diamond grinding wheel for grinding cast iron ,alloy steels , grey iron , hard composite materials and metal profile in foundry industry.

► Application: harder alloys, ceramics and cermet.
► Bonded: resin bond

► Single point diamond dressers
► Multi point diamond dressers
► Forming diamond dresser
► Impregnated diamond dressers
Application:dressing straight type conventional abrasive wheels. Dressing ceramic abrasive SG grinding wheels ,simple profiles, thread and gear grinding

Main features of CNC profile grinding wheels
Perfect processing quality
High efficient grinding with fast feeding
Good wear resistance and shape keeping
Applications of cnc grinding wheel
Mainly used for grinding digital controlled cutting tools such as tungsten carbide, high speed steel, stainless drill, mill and rimer.
Type: 1a1, 14a1, 11v9, 1v1, 12v9, 14f1

Resin grinding wheels are used for flute grinding high-speed steel cutting tools such as drills,end mills,taps,reamers,central drills and broach etc
CNC Grinding Machine: HERTLEIN,NORMAC,GUHRING,JUNKER,LIDKOPPING etc.

Grain size selection of vitrified diamond grinding wheel
► W40(500# D35) W28(D20) Rough Grinding.
► W20 (800# -1000#, D20) Universal Grinding.

► W10 (1500# D15A) W7 (2000# D15B) Finish Grinding.
► W5 (3000# D7) W3.5 (4000# D3) Super Finish Grinding.
Vitrified diamond grinding wheels for grinding PCD & PCBN cutting tools, CVD tools, MCD tools, milling cutter, reamer, drill and regrinding, etc

Type code:
14F1 Flat shape
Abrasive material:
Diamond & CBN
Bond:
Resin/Bronze/Vitrified/Electroplated
wheel base:
solid Alu body for Resin bond,solid #45 steel for Metal bond
Coarse Grit:
80#/100#/120#/140#/170#/200#/240#/270#/325#
Fine grit:
400#/500#/600#/800#/1000#/1200#/1500#/2000#/3000#
Diamond Concentration:
50%,75%,100%,125%

Moresuperhard’s customer uses a Japanese Koyo vertical double-end grinding machine with a rotary feedthrough type to grind air conditioning compressor slides.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

► Bond: Metal nickel plating electroplated bond & Resin bond (resin bond also consists of flexible and hard type)
► Length: 150mm – 5000m
► Width: 5mm – 350mm
► Grit: #60,#100,#120,#200,#400,#800,#1500,#2000,#3000,#5000
