Resin CBN Wheels Supplier for Woodworking Tool Grinding

Resin diamond grinding wheels are used for round cutting tools on cnc machine, including drills, milling cutters, reamers, taps, etc. The main materials are cemented carbide, high-speed steel, stainless steel and so on.
Model: 1a1, 12v9, 11v9, 12a2, 1v1, 14a1, 6a2, etc
Bonded: resin bond, metal bond and hybrid bond

► Application: harder alloys, ceramics and cermet.
► Bonded: resin bond

Best suited for demanding applications where a harder-wearing, longer-lasting blade is required.
specifications can be made according to customers requirements.
FOR CUTTING THE UNMACHINABLES
Hardest material known grinds the hardest, most brittle, and most abrasive applications
– High Heat Resistance
– High Abrasion Resistance

The self-sharpening for carbide saw blade is better, no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on

► Edge wheel for silicon and sapphire wafer edge grinding. A small diameter wheel is used for notch grinding
► Metal diamond wheel for rough grinding to get an accurate edge profile
► Resin diamond wheel for finish grinding to get good surface roughness

As a supplier of high-quality design, production and processing, Moresuperhard can provide customers with efficient grinding solutions. Welcome to contact us at any time!

The diamond resin grinding wheel has a good polishing effect. The grinding wheel is sharp and not easy to be blocked during grinding.
The specific characteristics are as follows:
1. The grinding efficiency is high, and the grinding wheel consumption is relatively slow;
2. Good self-sharpening, low heat generation during grinding, not easy to block, reducing the phenomenon of work burns during grinding;
3. The grinding wheel has a certain elasticity, which is conducive to improving the roughness of the workpiece surface. It is mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes;
4. The diamond resin grinding wheel is cured at low temperature, the production cycle is short, and the equipment and supply process is relatively simple; due to the fluidity of the resin, it is easy to form a grinding wheel with complex surfaces

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

► Application: grinding carbide and HSS. (such as drill, end mill, reamer)
► A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
► Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc
Resin bond diamond wheels for grinding tungsten carbide and HSS steel. Such as drills, end mills, reamers, micro drills, mini end mills and burrs, etc
Suitable CNC Grinding Machine: ANCA,WALTER,SCHUTTE,EWAG,SCHNEEBERGER,HUFFMANN and so on.

Moresuperhard’s Electroplated CBN diamond grinding wheels for hip joint broach
► Body Type: steel core CBN wheel, aluminum core CBN wheel and plastic CBN wheel
► Diameter: 6 inches, 8 inches and 10 inch
► Thickness :1 inch, 1.5 inches and 2 inch
► Arbor hole:1/2 inch, 5/8 inch, 1-1/4 inch
► Radius edge: 1/4 inch
► Grain Size: 80#, 180#, 220#, 350#, 600#, 800#, 1200# etc.
Applicable grinder: sharpening woodturning tools (high-speed steel HSS) on a bench grinder
► Advantages: * Fast and cool cutting action without coolant
* No need to dress or turn

The bond strength of this type of diamond grinding wheel is weaker than that of other wheels. The self-sharpening for carbide saw blade is better, with no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on

Resin grinding wheels are used for flute grinding high-speed steel cutting tools such as drills,end mills,taps,reamers,central drills and broach etc
CNC Grinding Machine: HERTLEIN,NORMAC,GUHRING,JUNKER,LIDKOPPING etc.

Resin diamond wheels for grinding tungsten carbide and HSS steel. Such as drills, end mills, reamers, micro drills, mini end mills and burrs, etc
Type: 1A1,1V1,1A1R,6A2,6A9,3A1,9A1,11V9,12A2,14A1 etc.
Moresuperhard has more than 15 years’ experience in producing diamond and cbn grinding wheels.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Resin bond diamond mounted point is an abrasive tool used for fast stock removal which lasts longer for about four times compared to conventional aluminum oxide mounted points. This makes it a very efficient tool as its increases productivity and clearly cleans more parts in less time. This mounted point is mainly used for machining tungsten carbide cutting tools, optical glass, gem, semi-conductor materials, non-ferrous materials, ceramic, magnetic materials, silicon, glass, quartz, thermal spraying alloy, and non-metallic material grinding.

► Application: harder alloys, ceramics and cermet.
► Bonded: resin bond

The Wheel Dresser is designed to provide easy and efficient dressing of diamond /CBN grinding wheels and grinding wheel spindles consisting of several grinding wheels.
►Diamond & CBN wheel dressing machine Models NM-X3 NM-X5 NM-X6
►Applications: -Dressing diamond /CBN grinding wheels -Dressing flat, side, angular, external and profile wheels -Single and multiple wheel combinations

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or hss drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.
Advantages of micro tool grinding wheel:
* Good edge stability
* High cutting efficiency
* Minimal reject-part rates
* Good round tool quality

►Material: Diamond
►Surface Treatment: As the picture shows
►Type: Bullet/Inverted Trapezoid/Ball/Round Head Cylinder/Flat Head Cylinder
►Tip Diameter：12mm 14mm 16mm 18mm 20mm 25mm or be customized.
►Shank Diameter：6mm, 6.35mm or be customized.

Diamond grinding wheels are mainly used for the processing and grinding of grooving, shovel back and end teeth of CNC tools such as solid carbide, high-speed steel, stainless steel drills, milling cutters and reamers.
Bonded: resin bond and hybrid bonded.
Model: 1a1, 1v1, 14a1, 11v9, 12v9, etc

— High-precision, high-efficiency
— Center-going, step-difference forming external cylindrical grinding
— The punches and needles are rough and finely ground at one time, and the finish is high
— With less frequent dressing in the case of vitrified CBN wheels or without dressing in the case of plated CBN wheels

For Woodworking Industry, Resin bond Diamond and CBN Wheels are the best choices. The applications include sharpening and production grinding. With more than 10 years of experiences, Moresuperhard has developed the premium bonds for this application. We provide both standard specs and Custom made wheels.

1.Resin Bond Diamond wheel is to grind Tungsten Carbide tipped tools and saws.
2.Resin Bond CBN wheel is to grind the circular saws and band saws made from HSS,
tool steel, and Stellite type material.
3. Resin CBN wheel is to grind the tool made from the combination of Carbide and hardened Tool Steel.

As a company that provides efficient grinding solutions to our customers, Moresuperhard conducts strict quality control on all products we produce. Come and have a look at our quality inspection process!

Diamond CBN grinding wheel heads are used because of their durability and their ability to cleanly cut the harder alloys, ceramics and cermet.

Body Material: Aluminum or Steel
Grain size: all grain size can be customized
Usage: grinding, sharpening, polishing
Bond: resin,vitrified,electroplated,metal bond are also available
Work piece: metal,HSS,tungsten carbide,glass,stone…etc
Size: all sizes,like 100mm,150mm,175mm,200mm,250mm….etc

► Application: grinding various precision ceramic

► Bonded: resin bond & vitrified bond

► Correct choice of grain size and bonded
* Usually rough grinding uses D126, D91 (Resin bond &Vitrified bond)
* Semi-rough grinding uses D76, D64, D54, D46 (Resin bond & Vitrified bond)
* Semi-finish grinding uses D25, D20 (Resin bond &Vitrified bond)
* Finishing grinding uses D15 (Resin bond)
* Super finishing uses D7, D1 (Resin bond)

►It is used for grinding and cylindrical grinding of cemented carbide measuring tools, tungsten steel, high-speed steel, alloy steel, glass, precious stones, jade, jade, amber, beeswax, magnetic materials, ceramics, molds, etc..
►And can also be used for plunge grinding and forming Grinding is an ideal tool for grinding hard and brittle materials and hard alloys due to the characteristics of diamond abrasives (high hardness, high compressive strength, and good wear resistance).

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with a vitrified grinding wheel the effect is more outstanding.
Many breakthroughs have been made in PCD composite material, CBN composite material and tungsten carbide processing, thus the application range of grinding wheels is wider.
Application: grinding camshaft in automobile

► Customized cutting, grinding, sharpening, brazing, regrind and retipped solution and service
► Bonded: vitrified bond, resin bond, metal bond
► Model: diamond cup wheel (6A2, 11A2, 1A2)

► Width: 3mm – 20mm
► Grain Size up to super finish #3000
► Cutting-edge chipping <5 μm

Moresuperhard provides a line of solution and services for ultra performance cnc tools grinding on CNC machines.
Fluting, gashing, OD grinding tungsten carbide, HSS, milling cutter, reamer and drill, etc
Applicable cnc machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

PCD materials are mainly divided into three categories according to the particle size:
coarse particle size (20-50μm),
medium particle size (about 10μm)
fine particle size (-5μm).
The coarser the particle size, the more difficult it is to grind. The coarse particle size tends to be jagged after grinding. , The quality is poor, but the wear resistance is the strongest; the fine-grained grinding is easier, and the quality of the cutting edge after grinding is better.
Vitrified diamond grinding wheels are used for grinding pcd cbn carbide ceramic cermet cutting tools
