Chine Manufacturer with High Speed Grinding Wheels Machine

►Can meet all grinding needs. It can also sharpen and remove hard materials.
►Cylindrical tip, diamond coated head.
►Can be installed on the electronic grinder, hanging mill and hand electric drill.
►Used for sculpturing, dressing, precision grinding and internal grinding carbide in ceramic, glass, precious stone, alloy and many other abrasive materials.
►Shape:Round Ball Shape.

Application Of Diamond/CBN Glass Wheels
Glass grinding and edging, coarse grinding, middle grinding and fine grinding etc.
* Full segment wheel
* Internal segment wheel
* Continuous wheel
Glass grinding and edging, coarse grinding, middle grinding and fine grinding etc.

Feartures Of Diamond Burs, Diamond Mounted Points
* With different sizes and coarseness
* Various shapes include, bullet, cone,round cylinder,barrel, flat top cylinder and dental, etc

* Fit Dremel type and rotary tools
* High grinding effect and long using life
* Convenient to grind, simple to use, safe and reliable
* No dust pollution, high performance ratio

Film belt is for grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum-magnesium alloy, aluminum beryllium alloy, titanium alloy and etc. hard brittle materials.

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor .

► Body type: ID Wheel with Shank, ID Wheel without Shank
► Model type: 1A8, 1A1W, 1A1, DWA
► We can offer: abrasive internal grinding wheels (PA, SG), CBN internal grinding wheels, Diamond internal grinding wheel

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

1.Resin Bond Diamond wheel is to grind Tungsten Carbide tipped tools and saws.
2.Resin Bond CBN wheel is to grind the circular saws and band saws made from HSS,
tool steel, and Stellite type material.
3. Resin CBN wheel is to grind the tool made from the combination of Carbide and hardened Tool Steel.

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.

Main Application
Resin bond grinding wheels have strong competitive advantages in the processing fields of carbide tools, ceramics, glass, PCBN tools, PDC cutter, Steel, cast iron, electronic information components precision cutting etc.

Moresuperhard provides complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding.
Models of cnc grinding wheels: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc
Applications of resin bond diamond grinding wheels: grinding carbide and HSS. (such as drill, end mill, reamer)

►Ideal for difficult to grind steel
►Faster stock removal cooler cutting
►Superior form holding

Film belt is for grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum-magnesium alloy, aluminum beryllium alloy, titanium alloy and etc. hard brittle materials.

Moresuperhard provides qualified services For DANOBAT Precision Grinding Machines.
Centerless grinding models：VG, DVG

► Resind diamond/CBN grinding wheels
► Conventional grinding wheels
► Diamond dressing wheels

Moresuperhard has been found on the determination to make a conspicuous commitment to serve high quality of diamond grinding wheels for tungsten carbide. diamond grinding wheels for tungsten carbide have been specifically developed to meet the demanding needs of precision cutting tool manufactures as well as re-sharpeners.

Resin Bond diamond and CBN grinding wheels are made of either phenolic or polyimide resins. Pressure and heat are utilized to bond the resin to our grinding wheel cores.
Moresuperhard’s phenolic bonded wheels can be utilized in dry or wet applications.
Our polyimide bonded wheels are best utilized in water or oil-based coolants for improved form holding, typically required in CNC tool and cutter applications.
Moresuperhard produces wheel sizes from 1in. (25mm) to 28 inches (720mm) and grit sizes from 40 to 3000 are available.

Flute grinding wheels are specially engineered high density (near zero porosity), resin bonded wheels which ensure that the form is generated with utmost precision and finesse.
Features Of Flute Grinding Wheel
* High intensityperipheral speed 80m/s
* Anti-impact:bearing larger grinding pressure
* Suitable self-sharpening:larger remove grinding without burning
* Excellent balance:no vibration cracks

Applications of diamond glass saw blade: cutting different types of glass (such as glass mosaic, sheet glass, crystallized glass, glass tile, coated glass, etc)
Size of glass cutting blades: 4″- 16″
►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use

Vitrified bond CBN Grinding Wheel is suitable for high-efficient heavy grinding of a camshaft of automobile parts. The wheel speed is 80m/s-160m/s, designed to be used on CNC Cam Grinders like Toyoda, Schaudt, Landis, Junker, etc.
Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor.

Selected diamond abrasive grains
Resin bond which has high precision
Diameter 125mm, Hole 20mm Grit 150#
Used for tungsten carbide, optical glass, gem
Default grit is 150#, Customized shape size and grit is available.

More SuperHard provides a line of solution and services for ultra performance cnc cutting tools grinding on CNC machines. Our services include fluting, gashing clear edge and relief angle, OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable cnc machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor.

► Body type: ID Wheel with Shank, ID Wheel without Shank

► Model type: 1A8, 1A1W, 1A1, DWA

► We can offer: abrasive internal grinding wheel (PA, SG), CBN internal grinding wheel, Diamond internal grinding wheel.

Moresuperhard’s vitrified CBN grinding tools with highest grinding layer for extended wheel life on the machine. Due to the special manufacturing process very high grinding layers on wheels are possible to shorten the setup-costs in the grinding process.

Features of vitrified CBN grinding wheels:
► longer wheel life
► shorter grinding cycle times
► automated grinding production capabilities with wheels dressed right on the grinder
Vitrified CBN products are ideal for steel and ferrous alloy grinding applications in automotive, aerospace, medical, production tooling, etc. They are excellent thermal conductors and do not react with ferrous materials during the grinding process like diamond does.

– Semi Closed Grinder
– Full Cover Grinder
– With Manipulator Grinder
– With Robot Grinder
CNC cylindrical grinder can not only be available for producing shapes like cylinders, but also shapes including cam, ellipse, or crankshaft
CNC grinding machines offer greater flexibility and easier operation

For Woodworking Industry, Resin bond Diamond and CBN Wheels are the best choice. The applications include sharpening and production grinding. With more than 10 years of experiences, Moresuperhard has developed the premium bonds for this application. We provide both standard specs and Custom made wheels.

1.Resin Bond Diamond wheel is to grind Tungsten Carbide tipped tools and saws.
2.Resin Bond CBN wheel is to grind the circular saws and band saws made from HSS,
tool steel, and Stellite type material.
3. Resin CBN wheel is to grind the tool made from the combination of Carbide and hardened Tool Steel.

Resin diamond wheels for grinding tungsten carbide and HSS steel. Such as drills, end mills, reamers, micro drills, mini end mills and burrs, etc
Type: 1A1,1V1,1A1R,6A2,6A9,3A1,9A1,11V9,12A2,14A1 etc.
Moresuperhard has more than 15 years’ experience in producing diamond and cbn grinding wheels.

► Customized cutting, grinding, sharpening, brazing, regrind and retipped solution and service
► Bonded: vitrified bond, resin bond, metal bond
► Model: diamond cup wheel (6A2, 11A2, 1A2)

► Width: 3mm – 20mm
► Grain Size up to super finish #3000
► Cutting-edge chipping <5 μm

Features:
High precision and efficiency grinding performance.
Long service life, meaning that the wheels will not wear out quickly.
Good thermal stability, ensuring that the wheels maintain their shape and size.
Chemically stable and corrosion-resistant materials are used, ensuring that the wheels do not rust or corrode.
The wheels are designed to be lightweight and easy to use.
