Precision grinding tools for the semiconductor industry

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor .

► Body type: ID Wheel with Shank, ID Wheel without Shank
► Model type: 1A8, 1A1W, 1A1, DWA
► We can offer: abrasive internal grinding wheels (PA, SG), CBN internal grinding wheels, Diamond internal grinding wheel

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

►It is used for grinding and cylindrical grinding of cemented carbide measuring tools, tungsten steel, high-speed steel, alloy steel, glass, precious stones, jade, jade, amber, beeswax, magnetic materials, ceramics, molds, etc..
►And can also be used for plunge grinding and forming Grinding is an ideal tool for grinding hard and brittle materials and hard alloys due to the characteristics of diamond abrasives (high hardness, high compressive strength, and good wear resistance).

For Woodworking Industry, Resin bond Diamond and CBN Wheels are the best choices. The applications include sharpening and production grinding. With more than 10 years of experiences, Moresuperhard has developed the premium bonds for this application. We provide both standard specs and Custom made wheels.

1.Resin Bond Diamond wheel is to grind Tungsten Carbide tipped tools and saws.
2.Resin Bond CBN wheel is to grind the circular saws and band saws made from HSS,
tool steel, and Stellite type material.
3. Resin CBN wheel is to grind the tool made from the combination of Carbide and hardened Tool Steel.

►High Precision Centerless Grinding Machines Models:
-FX12CNC
-FX18CNC-4

►Broad Applications:
-Automotive Industry: shafts, pins, valves, and bearings
-Aerospace Industry: turbine shafts, landing gear components, and fuel system parts
-Medical Industry
-Tool and Die Industry
-Bearings industry
-Tool and Die Industry: cutting tools, punches, and dies with high accuracy and surface quality

High Precision with High Rigidity Body Structure

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with vitrified grinding wheels the effect is more outstanding. The diameter range, the thickness range and the grit size range can be customerized according to customers’ requirement.

Metal bonded diamond wheels are best suited for edge rough grinding and have coarser diamonds for higher material removal. The diamonds are embedded in a sintered metal matrix. These wheels can either have a segmented pattern for edge rough grinding or a continuous pattern for fine grinding.
Features:
Wear resistant with a longer service life
The higher material removal rate
High grinding efficiency

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

1.Constant power section design reduces the cost of the inverter.
2.Reliable life with the application of P4 precision ceramic ball bearings.
3. Low heat loss with use of Copper rotor motor or imported motor.
Based on the above features, our high frequency and high speed spindles play the important role in improving the production efficiency and machining quality.

Cylindrical Grinder Models: FX27P-60 CNC, FX32P-100 CNC
– Semi Closed Grinder
– Full Cover Grinder
– With Manipulator Grinder
– With Robot Grinder

CNC cylindrical grinder can not only be available for producing shapes like cylinders, but also shapes including cam, ellipse, or crankshaft

Brazing diamond tool is a tool product which solders a layer of diamond firmly on the metal matrix through the melting process of metal solder. This kind of product has the characteristics of higher efficiency, the long service life of a single diamond particle and high grinding accuracy. The main products cover all coarse and medium-sized electroplated diamond tools and some hot-pressed diamond tools.
In order to avoid the problems of low holding power, small chip space, low exposure height and easy falling off caused by traditional manufacturing methods, and to make greater use of the advantages of single-layer diamond tools, brazing technology has been applied to the field of diamond tools manufacturing since 2000 and has developed rapidly. Brazing technology, as a new manufacturing method of diamond tools, has attracted wide attention all over the world.

► Edge wheel for silicon and sapphire wafer edge grinding. A small diameter wheel is used for notch grinding
► Metal diamond wheel for rough grinding to get an accurate edge profile
► Resin diamond wheel for finish grinding to get good surface roughness

Resin bond diamond grinding wheel for grinding and resharpening carbide drills; Resin bond Cubic Boron Nitride grinding wheel for grinding and resharpening high-speed steel drills.
Advantages:
High grinding efficiency；
High material removal rate；
High tools surface finish and good cutting edge quality；
The shape of the grinding wheel is kept well；
High machining accuracy；
Low loss, low thermal damage, no burn of workpiece；
Wear-resistant, long working life；

We provides a line of solution and services for ultra performance tools grinding on CNC machines. Our services include,
► Fluting
► Gashing clear edge and relief angle
► OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc

Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

► Application: harder alloys, ceramics and cermet.
► Bonded: resin bond

►High Precision CNC lnternal Grinder Models:
-IG150
-IG150 I (Elongated)

►Broad Applications:
The inner cylinder, the inner cone and the end face of the step shaft：
– Transmission gear hole grinding
– Air conditioning warping
– Bearing
– Ring gauge

Moresuperhard provides qualified services For DANOBAT’s Precision Grinding Machines.
Centerless grinding models：ESTARTA-175 / ESTARTA-250, ESTARTA-400 / ESTARTA-650

► Resind diamond/CBN grinding wheels
► Conventional grinding wheels
► Diamond dressing wheels

► Diamond; CBN honing stone, honing stick
► Bonded: metal bond
► Materials of workpiece: carbide,glass and ceramic,cast iron,alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
► Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.

Vitrified diamond grinding wheels are suitable for grinding, regrinding cutting tools (such as carbide, ceramic, cermet, pcd, pcbn, cvd, mcd)
Custom PCD tools, CBN tools, CVD diamond tools and Mono Crystal diamond tools cutting, brazing, grinding, sharpening, regrind and retipped service and solution.

MORESUPERHARD has more 10 years of manufacturing experience and a strict production control and management system. Our grinding wheels are rigorously tested from raw material to finished product.

Grinding machine information: The customer mainly makes compressor parts and has LAPMASTER and 20 Speedfam double-end grinding machines.
Processing method: before the polished way more, now consider switching to the grinding way.
Processing details: The compressor valve plate is 420 stainless steel, most of the low carbon steel and bearing steel on the market are more, and there are no successful cases of stainless steel grinding.
Feedback: The rough grinding with diamond double-end grinding discs is very efficient, and the fine grinding with CBN double-end grinding discs is very good in terms of finish.

► Model: 1A1R, 1A1, 3A1, 1V1, 4A2, 4BT9, 6A2, 11V9, 12A2, 14F, etc
► Workpiece Materials: grinding tungsten carbide cutting tools, ceramic , magnetic materials, silicon , sapphire, glass , quartz and HVOF carbide coated,PCD, PCBN, etc
► Applicable Industry: carbide inserts (cnc tools), carbide circular saw (woodworking tools), Thermal Spraying Coated, Silicon Wafer Grinding, etc

► Customized cutting, grinding, sharpening, brazing, regrind and retipped solution and service
► Bonded: vitrified bond, resin bond, metal bond
► Model: diamond cup wheel (6A2, 11A2, 1A2)

► Width: 3mm – 20mm
► Grain Size up to super finish #3000
► Cutting-edge chipping <5 μm

► Customized cutting, grinding, sharpening, brazing, regrind and retipped solution and service
► Bonded: vitrified bond, resin bond, metal bond
► Model: diamond cup wheel (6A2, 11A2, 1A2)

► Width: 3mm – 20mm
► Grain Size up to super finish #3000
► Cutting-edge chipping <5 μm

► Grinding Indexable inserts (tungsten carbide inserts, ceramic inserts, CBN inserts)
► Model: 6A2T, 6A2M, 11A2B, 12A2T
► Grinding Machine: WENDT, WAIDA, AGATHON, EWAG, COBORN, etc.

► Application: grinding carbide, ceramic, magnetic materials, stainless steel bar, PCD & PCBN compositives
► Model: 1A1 , 6A1, 9A1
► Bonded Type: Resin bond, Metal bond
► Centerless Grinder Machine: Koyo, Crystec, Dedtru, Landis , Okuma, Paragon, Royal Master, Unison, WMV

1. High production efficiency, long service life and low cost of dressing of individual parts.
2. It can maintain the stability of parts precision and the high qualified rate of products for a long time.
3.For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results.
4. Easy to operate.
5. High utilization of CNC machine , easy to achieve automation and mass production.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Resin grinding wheels are used for flute grinding high-speed steel cutting tools such as drills,end mills,taps,reamers,central drills and broach etc
CNC Grinding Machine: HERTLEIN,NORMAC,GUHRING,JUNKER,LIDKOPPING etc.

Features:
High precision and efficiency grinding performance.
Long service life, meaning that the wheels will not wear out quickly.
Good thermal stability, ensuring that the wheels maintain their shape and size.
Chemically stable and corrosion-resistant materials are used, ensuring that the wheels do not rust or corrode.
The wheels are designed to be lightweight and easy to use.
