China Manufacturer Carbide Cutter Sharpening 4a2 diamond grinding wheels

► Application: precision grinding micro drill tools
Advantages of micro tool grinding wheel:
* Good edge stability
* High cutting efficiency
* Minimal reject-part rates
* Good round tool quality

For natural diamond (MCD) or synthetic single crystal diamond (SCD)cutting tools.

Resin bond diamond & CBN grinding wheels have features of good self-sharpening, low heat generated during grinding, not easy to block and reduce the phenomenon of working burns during grinding. Resin bond has a certain elasticity and is conducive to improving the roughness of the workpiece surface, mainly used for fine grinding, semi-fine grinding, sharpening grinding, polishing and other processes. Therefore, resin bond diamond and CBN grinding wheels are widely used in the field of grinding and cutting.

Dressing Diamond or CBN wheel at operating speed then start the truing wheel spinning in the direction of rotation of the Diamond or CBN  wheel at point of contact, in other words in the same direction it will rotate when driven by the Diamond or CBN  wheel.
Superabrasive grinding wheels are used for grinding carbide and HSS. (such as drill, end mill, reamer)
Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc

4a2 Diamond and CBN grinding wheels for woodworking industry.
Applications of 4a2 diamond cup wheels: used for grinding top, face and side grinding the circular saw blades and band saws (made of tungsten carbide, cermet and pcd) , woodwork drills and mills.

Features:
High precision and efficiency grinding performance.
Long service life, meaning that the wheels will not wear out quickly.
Good thermal stability, ensuring that the wheels maintain their shape and size.
Chemically stable and corrosion-resistant materials are used, ensuring that the wheels do not rust or corrode.
The wheels are designed to be lightweight and easy to use.

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor .
► Body type: ID Wheel with Shank, ID Wheel without Shank
► Model type: 1A8, 1A1W, 1A1, DWA
► We can offer: abrasive internal grinding wheels (PA, SG), CBN internal grinding wheels, Diamond internal grinding wheel

PDC Blanks for Korean Customer

■ Due to its self-sharpening, resin bond wheel is easy to use and is suitable for roughing – finishing.
■ Due to moderate abrasive holding strength and wear-resistance, this wheel is suitable for roughing with free cutting.
■ Due to elasticity, this wheel using fine grits is suitable for finishing.

• Reduction of dressing costs per workpiece
• Optimized utilization of machine capacity
• Automation of the dressing process
• Repeatable high precision with low workpiece rejects
• Rapid incorporation of complex profiles in the grinding wheel

Characteristics of CNC Cylindrical Grinder
• The grinding wheel spindle has high rigidity, high precision, high service life and low vibration and low friction
• The self-aligning function, the wheel spindle is not affected by the belt tension and is biased
• The spindle has a centering and simultaneous compound function, and the user can perform rapid conversion in the core machining and the chuck clamping process.
• The Z-axis consists of an AC servo motor, a high-precision bead screw, and an automatic forced lubrication system
• High repeatability. long track service life, high rigidity and smooth reciprocating motion
• Configurable surface measurement, outer diameter thickness measurement, grinding wheel anti-collision device

Resin bond grinding wheels are versatile enough to be used wet or dry for most tool making, resharpening and toolroom reconditioning applications.
Applications: Diamond for carbide or inlaid carbide/steel (Bak-Pak); CBN for HSS, Jonalloy, or Stellite
Machine type: Available for all CNC and manual profile grinders using oil or Water coolant. Schneeberger, Walter, Wadkin, Foley, SCMI, United, Tigra, Andi, Nielson
Grinding wheel types: 1A1R, 1F1R, 14A1R, 14F1R

How to grinding pcd tools with the diamond wheels
Moresuperhard provides custom PCD tools, CBN tools, CVD diamond tools and Mono Crystal diamond tools cutting, brazing, grinding, sharpening, regrind and retipped service and solution.

Application: carbide, tungsten steel, vitrified optical glass, sapphire glass, high-speed steel, bearing steel, tool steel, stainless steel, and cast iron, etc
► Bond: vitrified bond & resin bond
► Diameter: 300- 1500mm

► Provide matching dressing grinding wheel
►Diamond & CBN shapes: cylindrical, hexagonal, square, segmented
► Grinding machines: Wendt WBM, Viotoo, AMT, Stahli, Peter Wolters, Diskus, Agathon T&B, Fujisanki, Supfina, Melchiorre, Koyo, Lam Plan, Speedfam, Kemet, Gardner and other brands.

► Grinding Indexable inserts (tungsten carbide inserts, ceramic inserts, CBN inserts)
► Model: 6A2T, 6A2M, 11A2B, 12A2T
► Grinding Machine: WENDT, WAIDA, AGATHON, EWAG, COBORN, etc.

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Resin bond diamond grinding wheel for grinding and resharpening carbide drills; Resin bond Cubic Boron Nitride grinding wheel for grinding and resharpening high-speed steel drills.
Advantages:
High grinding efficiency；
High material removal rate；
High tools surface finish and good cutting edge quality；
The shape of the grinding wheel is kept well；
High machining accuracy；
Low loss, low thermal damage, no burn of the workpiece；
Wear-resistant, long working life；

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Peripheral Diamond Grinding wheels are used for indexable inserts grinding.
Peripheral Grinding tungsten carbide inserts, ceramic inserts, cermet, pcd and cbn inserts
Model: 6A2T, 6A2M, 11A2B, 12A2T
Bonded: resin bond and vitrified bond

– Semi Closed Grinder
– Full Cover Grinder
– With Manipulator Grinder
– With Robot Grinder
CNC cylindrical grinder can not only be available for producing shapes like cylinders, but also shapes including cam, ellipse, or crankshaft
CNC grinding machines offer greater flexibility and easier operation

►It is used for grinding and cylindrical grinding of cemented carbide measuring tools, tungsten steel, high-speed steel, alloy steel, glass, precious stones, jade, jade, amber, beeswax, magnetic materials, ceramics, molds, etc..
►And can also be used for plunge grinding and forming Grinding is an ideal tool for grinding hard and brittle materials and hard alloys due to the characteristics of diamond abrasives (high hardness, high compressive strength, and good wear resistance).

► Applications: face grinding, top grinding, flank grinding, hollow tooth grinding and re-sharpening for tungsten carbide tipped saw blades and one-piece HSS saws
► Models: 4A2, 4BT9, 11A2, 15A2, 12V2, 14F1, etc
► Bonded: Resin bond, vitrified bond
► Grinding Machine: Vollmer, Woodtronic, Akemat, Widma and so on

Application: sculpturing, dressing and internal grinding carbide, ceramic,glass, stones, marble,etc

Types of internal grinding wheel:
* vitrified cbn internal grinding wheel
* resin diamond & cbn internal wheel
* electroplated diamond mounted points
* abrasive internal grinding wheel

►High strength cast iron machine body
►Constant temperature cooling and unloading device can be configured
►Digital size control system
►Compressed protection for upper working disc

► Polishing and finishing of glass, LCD/LED substrates, precision optics, hard disk, metal and semiconductor wafer surfaces
► Model: MSH-66, MSH-77, MSH-13, MSH-LASER, MSH-46
► Thickness: 0.02″ (0.508 mm) – 0.20″ (5.08 mm)

More SuperHard provides a line of solution and services for ultra performance cnc cutting tools grinding on CNC machines. Our services include fluting, gashing clear edge and relief angle, OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable cnc machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

► Single point diamond dressers
► Multi point diamond dressers
► Forming diamond dresser
► Impregnated diamond dressers
Application:dressing straight type conventional abrasive wheels. Dressing ceramic abrasive SG grinding wheels ,simple profiles, thread and gear grinding

► Application: grinding carbide, ceramic, magnetic materials, stainless steel bar, PCD & PCBN compositives
► Model: 1A1 , 6A1, 9A1
► Bonded Type: Resin bond, Metal bond
► Centerless Grinder Machine: Koyo, Crystec, Dedtru, Landis , Okuma, Paragon, Royal Master, Unison, WMV
