1A1 carbide sharpening resin bond diamond grinding wheels

Thickness and Grit : customered
For grinding and polishing jewelry, glass, rock,stone, granite,etc.
Recommended for rough and fine grinding on faceting material plus general lapidary grinding when precision is required.

Vitrified CBN internal grinding wheels are made of cubic boron nitride abrasives and sintered with metal powder, resin powder and ceramic as a bonding agent to form various shapes of abrasives for industrial grinding, polishing and lapping.

Resin grinding wheels are used for flute grinding high-speed steel cutting tools such as drills,end mills,taps,reamers,central drills and broach etc
CNC Grinding Machine: HERTLEIN,NORMAC,GUHRING,JUNKER,LIDKOPPING etc.

The honing reamer is equipped with reasonable joints, tools and machine tools, which can achieve the ultra-high precision of the inner hole: Cylindricity: ≤1 μm, Roundness: ≤ 1 μm, Roughness: ≤Ra0.1, Tolerance: ≤1μm

Vitrified bond CBN Grinding Wheel is suitable for high-efficient heavy grinding of a camshaft of automobile parts. The wheel speed is 80m/s-160m/s, designed to be used on CNC Cam Grinders like Toyoda, Schaudt, Landis, Junker, etc.
Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor.

Moresuperhard provides qualified services For DANOBAT’s Precision Grinding Machines.
Centerless grinding models：ESTARTA-175 / ESTARTA-250, ESTARTA-400 / ESTARTA-650

► Resind diamond/CBN grinding wheels
► Conventional grinding wheels
► Diamond dressing wheels

► Grinding, regrind pcd, pcbn, cvd tools
► Bonded: vitrified bond, resin bond, metal bond
► Width: 1mm – 20mm

► Up to #10000 for super finish
► Cutting-edge chipping <5 μm ► Provide dressing wheel to dress PCD grinding wheel

►Accurately grinding Tungsten Carbide, Ceramic, Cermet, Steel HRC, Glass and Others, etc.
►Diameter 20- Diameter 900, customized as your request
►CBN+aluminum body

Resin Bond CBN Grinding Wheel feature:
1）high efficiency；
2）abrasion resistance, high consumption
3）Small grinding force, grinding temperature is low
4）high accuracy and good surface quality of the workpiece, the shape of the workpiece stability is good
5）with more pores, grinding is good for chip removal and cooling, not easy to jam, and not easy to burn the workpiece
6）easy sharping

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

► Diamond; CBN honing stone, honing stick
► Bonded: metal bond
► Materials of workpiece: carbide,glass and ceramic,cast iron,alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
► Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.

► Customized cutting, grinding, sharpening, brazing, regrind and retipped solution and service
► Bonded: vitrified bond, resin bond, metal bond
► Model: diamond cup wheel (6A2, 11A2, 1A2)

► Width: 3mm – 20mm
► Grain Size up to super finish #3000
► Cutting-edge chipping <5 μm

MORESUPERHARD is a professional manufacturer of grinding, cutting, polishing and dressing tools. Thanks to abundant experience in surface treatment, we design and offer a complete grinding and dressing solution to our customers in various industries. With innovative and creative development conception, MORESUPERHARD is tirelessly striving to provide excellent design, superior quality and perfect service to world-wide customers. We have devoted to offer various diamond & CBN wheels for carbide, HSS, PCD, PCBN machining according to customers’ requirements and FEPA Standard.

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

PCD materials are mainly divided into three categories according to the particle size:
coarse particle size (20-50μm),
medium particle size (about 10μm)
fine particle size (-5μm).
The coarser the particle size, the more difficult it is to grind. The coarse particle size tends to be jagged after grinding. , The quality is poor, but the wear resistance is the strongest; the fine-grained grinding is easier, and the quality of the cutting edge after grinding is better.
Vitrified diamond grinding wheels are used for grinding pcd cbn carbide ceramic cermet cutting tools

As a supplier of high-quality design, production and processing, Moresuperhard can provide customers with efficient grinding solutions. Welcome to contact us at any time!

More Superhard provides precise solutions for cylindrical grinding PDC cutter, repairing PDC drill bits in Oil & Gas industry. We can supply diamond tools include,
► Vitrified Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Resin Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Cylindrical Diamond Wheel for PDC Cutter chamfer grinding
Model: 1A1,14A1 diamond wheel (diameter up to 1100mm)

The self-sharpening for carbide saw blade is better, no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on.

Moresuperhard provides a line of solution and services for ultra performance tools grinding on CNC machines. Our services include,
► Fluting
► Gashing clear edge and relief angle
► OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

Application: sculpturing, dressing and internal grinding carbide, ceramic,glass, stones, marble,etc

Types of internal grinding wheel:
* vitrified cbn internal grinding wheel
* resin diamond & cbn internal wheel
* electroplated diamond mounted points
* abrasive internal grinding wheel

► Bonded: vitrified bond, resin bond, metal bond
► Width: 1mm – 20mm
► Up to #10000 for super finish
► Cutting-edge chipping <5 μm ► Provide dressing wheel to dress PCD grinding wheel

► Grinding Indexable inserts (tungsten carbide inserts, ceramic inserts, CBN inserts)
► Model: 6A2T, 6A2M, 11A2B, 12A2T
► Grinding Machine: WENDT, WAIDA, AGATHON, EWAG, COBORN, etc.

1. High production efficiency, long service life and low cost of dressing of individual parts.
2. It can maintain the stability of parts precision and the high qualified rate of products for a long time.
3. For some parts whose complex surface or other imitation dressing is difficult to meet the requirements, the Rotary dresser can obtain satisfactory results.
4. Easy to operate.
5. High utilization of CNC machine, easy to achieve automation and mass production.

The diamond resin grinding wheel has a good polishing effect. The grinding wheel is sharp and not easy to be blocked during grinding.
The specific characteristics are as follows:
1. The grinding efficiency is high, and the grinding wheel consumption is relatively slow;
2. Good self-sharpening, low heat generation during grinding, not easy to block, reducing the phenomenon of work burns during grinding;
3. The grinding wheel has a certain elasticity, which is conducive to improving the roughness of the workpiece surface. It is mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes;
4. The diamond resin grinding wheel is cured at low temperature, the production cycle is short, and the equipment and supply process is relatively simple; due to the fluidity of the resin, it is easy to form a grinding wheel with complex surfaces

Manufacturing processes for silicon semiconductor
Silicon Ingot ⇒ Cropping(electroplated bandsaw) ⇒ Cylindrical / Flat Grinding Silicon Rod ⇒ Ingot Silicon (diamond wire) ⇒ Lapping (double side wheel/polishing pad) ⇒ Edge Grinding ⇒ Surface grinding ⇒ polishing⇒ wafer⇒ patterning ⇒ back grinding (vitrified / resin wheels) ⇒ dicing (dicing blades)⇒ chips ⇒ molding ⇒ packaging

► Application: grinding carbide, ceramic, magnetic materials, stainless steel bar, PCD & PCBN compositives
► Model: 1A1 , 6A1, 9A1
► Bonded Type: Resin bond, Metal bond
► Centerless Grinder Machine: Koyo, Crystec, Dedtru, Landis , Okuma, Paragon, Royal Master, Unison, WMV

► Application: Grinding engine valves (inlet valves and exhaust valves) in cars, motorcycles, trucks, and other engine valves
► Speed of CBN Wheel: 80-140 m/s
► No need to dress

► Application: precise grinding mould and die, punch pin, optical grinding and form grinding cutting tool ( such as end mill and reamer) and precise instrument
► Model: 3A1, 14K1, 1B9
► Bonded: resin bond & metal bond
► Optical Profile Grinder: Amada, Waida, Wasion, etc

The Wheel Dresser is designed to provide easy and efficient dressing of diamond /CBN grinding wheels and grinding wheel spindles consisting of several grinding wheels.
►Diamond & CBN wheel dressing machine Models NM-X3 NM-X5 NM-X6
►Applications: -Dressing diamond /CBN grinding wheels -Dressing flat, side, angular, external and profile wheels -Single and multiple wheel combinations

We provides a line of solution and services for ultra performance tools grinding on CNC machines. Our services include,
► Fluting
► Gashing clear edge and relief angle
► OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc

Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner
