Usage:
1. Especially used for internal grinding of complex workpieces.
2. Used for dressing abrasive tools.
3. Used for processing industrial ceramics.
4. Suitable for processing and polishing cemented carbide, various molds, stone, glass, jade, gems, teeth, bones, high-speed steel and various high-hardness materials.

Moresuperhard has different types of Vitrified Diamond Grinding Wheels.

Features:
High precision and efficiency grinding performance.
Long service life, meaning that the wheels will not wear out quickly.
Good thermal stability, ensuring that the wheels maintain their shape and size.
Chemically stable and corrosion-resistant materials are used, ensuring that the wheels do not rust or corrode.
The wheels are designed to be lightweight and easy to use.

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.

Main Application
Resin bond grinding wheels have strong competitive advantages in the processing fields of carbide tools, ceramics, glass, PCBN tools, PDC cutter, Steel, cast iron, electronic information components precision cutting etc.

Electroplated bond grinding wheels have characteristics of high grain density, sharp grinding, high efficiency, good precision, without dressing etc. The product can be made with various shapes and they are suitable for special complicated profile, super-thin, especially small and other form grinding which have strict requirement on geometry shape and dimension.

PDC Blanks for Korean Customer

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with a vitrified grinding wheel the effect is more outstanding.
Many breakthroughs have been made in PCD composite material, CBN composite material and tungsten carbide processing, thus the application range of grinding wheels is wider.

MORESUPERHARD has more 10 years of manufacturing experience and a strict production control and management system. Our grinding wheels are rigorously tested from raw material to finished product.

► Model: 1A1R, 1A1, 3A1, 1V1, 4A2, 4BT9, 6A2, 11V9, 12A2, 14F, etc
► Workpiece Materials: grinding tungsten carbide cutting tools, ceramic , magnetic materials, silicon , sapphire, glass , quartz and HVOF carbide coated,PCD, PCBN, etc
► Applicable Industry: carbide inserts (cnc tools), carbide circular saw (woodworking tools), Thermal Spraying Coated, Silicon Wafer Grinding, etc

Thickness and Grit : customered
For grinding and polishing jewelry, glass, rock,stone, granite,etc.
Recommended for rough and fine grinding on faceting material plus general lapidary grinding when precision is required.

► Application: grinding various precision ceramic

► Bonded: resin bond & vitrified bond

► Correct choice of grain size and bonded
* Usually rough grinding uses D126, D91 (Resin bond &Vitrified bond)
* Semi-rough grinding uses D76, D64, D54, D46 (Resin bond & Vitrified bond)
* Semi-finish grinding uses D25, D20 (Resin bond &Vitrified bond)
* Finishing grinding uses D15 (Resin bond)
* Super finishing uses D7, D1 (Resin bond)

Application: sculpturing, dressing and internal grinding carbide, ceramic,glass, stones, marble,etc

Types of internal grinding wheel:
* vitrified cbn internal grinding wheel
* resin diamond & cbn internal wheel
* electroplated diamond mounted points
* abrasive internal grinding wheel

– Metal diamond wheel for rough grinding to get accurate edge profile
– Grinded with uniform chamfer width, excellent rigidity
– Strong groove shape retention, long life
– By edge grinding the final diameter is adjusted
– A uniform CBN layer minimizes machining damage
– Highly precise slotted shape support various wafer shapes
It is suitable for making guide vanes and nozzle guide vanes for aviation jet engines, industrial gas turbines, naval gas turbines, and diesel engine nozzles.

Resin bond diamond grinding wheel for grinding and resharpening carbide drills; Resin bond Cubic Boron Nitride grinding wheel for grinding and resharpening high-speed steel drills.
Advantages:
High grinding efficiency；
High material removal rate；
High tools surface finish and good cutting edge quality；
The shape of the grinding wheel is kept well；
High machining accuracy；
Low loss, low thermal damage, no burn of workpiece；
Wear-resistant, long working life；

We provides a line of solution and services for ultra performance tools grinding on CNC machines. Our services include,
► Fluting
► Gashing clear edge and relief angle
► OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc

Our Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

Moresuperhard provides customized resin or electroplated diamond belts. There are many grinding advantages such as sharpness, durability, flexibility, and dry or wet grinding for diamond sanding abrasive belts with various patterns. Please choose different design patterns according to your needs.

► Applications: face grinding, top grinding, flank grinding, hollow tooth grinding and re-sharpening for tungsten carbide tipped saw blades and one-piece HSS saws
► Models: 4A2, 4BT9, 11A2, 15A2, 12V2, 14F1, etc
► Bonded: Resin bond, vitrified bond
► Grinding Machine: Vollmer, Woodtronic, Akemat, Widma and so on

With hydrostatic liquid suspension electric spindle, high rigidity, high speed, low vibration, high grinding force.
►Servo Surface CNC cylindrical grinder Models
GP32
J2
►Applications:
– automotive and aerospace industries,
– tool manufacturing
– die makingn

More Superhard provides precise solutions for cylindrical grinding PDC cutter, repairing PDC drill bits in Oil & Gas industry. We can supply diamond tools include,
► Vitrified Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Resin Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Cylindrical Diamond Wheel for PDC Cutter chamfer grinding
Model: 1A1,14A1 diamond wheel (diameter up to 1100mm)

► Application: grinding carbide and HSS. (such as drill, end mill, reamer)
► A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
► Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc

Grain size selection of vitrified diamond grinding wheel
► W40(500# D35) W28(D20) Rough Grinding.
► W20 (800# -1000#, D20) Universal Grinding.
► W10 (1500# D15A) W7 (2000# D15B) Finish Grinding.
► W5 (3000# D7) W3.5 (4000# D3) Super Finish Grinding.
Vitrified diamond grinding wheels for grinding PCD & PCBN cutting tools, CVD tools, MCD tools, milling cutter, reamer, drill and regrinding, etc

Main features of CNC profile grinding wheels
Perfect processing quality
High efficient grinding with fast feeding
Good wear resistance and shape keeping
Applications of cnc grinding wheel
Mainly used for grinding digital controlled cutting tools such as tungsten carbide, high speed steel, stainless drill, mill and rimer.
Type: 1a1, 14a1, 11v9, 1v1, 12v9, 14f1

• Reduction of dressing costs per workpiece
• Optimized utilization of machine capacity
• Automation of the dressing process
• Repeatable high precision with low workpiece rejects
• Rapid incorporation of complex profiles in the grinding wheel

Resin bonded grinding wheel is one of the most representative bond types used for super-abrasive grinding wheels. In general, it shows an excellent compromise between surface roughness, cutability, and long lifetime.
It’s mainly used for carbide, HSS, and ceramic cutting tool grinding applications.
(Genentech GB series)

Feature:
High stability in dry & wet conditions
Application:
General grinding of tungsten-carbide, HSS, Ferrous & Nonferrous metals

Advantages of vitrified diamond wheels for PCD and PCBN tools :
* The porous structure of the abrasive improved diamond exposure and Can Prevent Vertical Streaks On Workpiece And Improve Surface Quality
* Accurately control geometric tolerances to make a good abrasive layer
* Good Self-Sharpening, High Grinding Efficiency, High Wear Resistance And Less Abrasive Grain Consumption
* High Precision Workpiece. PCD Tools Can Reach High Efficiency, Good Surface Finish And Edge No Chipping
* Vitrified Bond Wheels Offer Tool Life Greater Than 150 Times That Of A Resin Bond Wheel And Can Be Easily Trued And Dressed On The Machine

►Ideal for difficult to grind steel
►Faster stock removal cooler cutting
►Superior form holding

► Suitable for all kinds of electric grinders, lapping machines, etc., grinding, lapping, surface grinding, efficient and fast
► Suitable for sandblasting, agate, glass, mold, etc., polishing, engraving, edge grinding and sewing, etc., efficient and save a lot of time
► The focus of the diamond ball grinding head is engraving, U-shaped surface engraving and hollow engraving
► To ensure the life of the tool, cooling with water is required, as the diamond will undergo patterning and wear due to overheating.

►It is used for grinding and cylindrical grinding of cemented carbide measuring tools, tungsten steel, high-speed steel, alloy steel, glass, precious stones, jade, jade, amber, beeswax, magnetic materials, ceramics, molds, etc..
►And can also be used for plunge grinding and forming Grinding is an ideal tool for grinding hard and brittle materials and hard alloys due to the characteristics of diamond abrasives (high hardness, high compressive strength, and good wear resistance).
