Diamond Wheels CBN Wheel Resin Grinding Wheels For Carbide China Manufacture

Porous Ceramic Chuck Tables are widely used as important components of equipment in silicon wafers, semiconductor compound wafers, piezoelectric ceramics, glass, LED, semiconductor package component substrate, optical component thinning, and cutting.

► Model: 1A1R, 1A1, 3A1, 1V1, 4A2, 4BT9, 6A2, 11V9, 12A2, 14F, etc
► Workpiece Materials: grinding tungsten carbide cutting tools, ceramic , magnetic materials, silicon , sapphire, glass , quartz and HVOF carbide coated,PCD, PCBN, etc
► Applicable Industry: carbide inserts (cnc tools), carbide circular saw (woodworking tools), Thermal Spraying Coated, Silicon Wafer Grinding, etc

► Application: inner grinding of bearing, compressor, CVJ ball-cage, hydraulic tappets, universal joint, stator and rotor.

► Body type: ID Wheel with Shank, ID Wheel without Shank

► Model type: 1A8, 1A1W, 1A1, DWA

► We can offer: abrasive internal grinding wheel (PA, SG), CBN internal grinding wheel, Diamond internal grinding wheel.

► Applications: polishing and faceting gemstones (jade, crystal, agate), spinel, sapphire, jewelry, glass artwork, and precision machining industry
► Bonded: resin bond, electroplated bond
► The grain size up to #15000
Features
Backed by a strong Aluminum base, these laps have a sturdy construction and last long.
Perfect for polishing soft gemstones.
Perfectly flat and parallel to the surface to ensure great balance and accuracy.

Film belt is for grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum-magnesium alloy, aluminum beryllium alloy, titanium alloy and etc. hard brittle materials.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

The self-sharpening for carbide saw blade is better, no blocking.
Diamond and CBN wheels for sharpening circular saw blades (TC, HSS)
Models of grinding wheel: 4A2, 4BT9, 4A9, 3A1, 14A1, 6V5, 6A2, 1A8W, 14F1, etc
CNC machines: Vollmer, Woodtronic, Akemat, Widma and so on.

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.

Main Application
Resin bond grinding wheels have strong competitive advantages in the processing fields of carbide tools, ceramics, glass, PCBN tools, PDC cutter, Steel, cast iron, electronic information components precision cutting etc.

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with vitrified grinding wheels the effect is more outstanding. The diameter range, the thickness range and the grit size range can be customerized according to customers’ requirement.

Moresuperhard provides a line of solution and services for ultra performance cutting tools grinding on CNC machines. Our services include,
► Fluting
► Gashing clear edge and relief angle
► OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Diamond and CBN wheels are available in resin bond and hybrid bond. The applicable machines include,Walter, Anca, Ewag, Vollmer, Rollomatic, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner

Diamond Polishing Paste, Diamond Compound is divided into a water-soluble polishing paste and an oil-soluble polishing paste.

More Superhard provides precise solutions for cylindrical grinding PDC cutter, repairing PDC drill bits in Oil & Gas industry. We can supply diamond tools include,
► Vitrified Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Resin Diamond Wheel for Cylindrical Grinding PDC Cutter / PDC Drill Bits
► Cylindrical Diamond Wheel for PDC Cutter chamfer grinding
Model: 1A1,14A1 diamond wheel (diameter up to 1100mm)

►Ideal for difficult to grind steel
►Faster stock removal cooler cutting
►Superior form holding

► Application: grinding carbide and HSS. (such as drill, end mill, reamer)
► A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
► Model: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc
Metal bond diamond wheels for grinding tungsten carbide and HSS steel. Such as drills, end mills, reamers, micro drills, mini end mills and burrs, etc
Suitable CNC Grinding Machine: ANCA,WALTER,SCHUTTE,EWAG,SCHNEEBERGER,HUFFMANN and so on.

►It is used for grinding and cylindrical grinding of cemented carbide measuring tools, tungsten steel, high-speed steel, alloy steel, glass, precious stones, jade, jade, amber, beeswax, magnetic materials, ceramics, molds, etc..
►And can also be used for plunge grinding and forming Grinding is an ideal tool for grinding hard and brittle materials and hard alloys due to the characteristics of diamond abrasives (high hardness, high compressive strength, and good wear resistance).

1.Resin Bond Diamond wheel is to grind Tungsten Carbide tipped tools and saws.
2.Resin Bond CBN wheel is to grind the circular saws and band saws made from HSS,
tool steel, and Stellite type material.
3. Resin CBN wheel is to grind the tool made from the combination of Carbide and hardened Tool Steel.

Application Of Diamond/CBN Glass Wheels
Glass grinding and edging, coarse grinding, middle grinding and fine grinding etc.
* Full segment wheel
* Internal segment wheel
* Continuous wheel
Glass grinding and edging, coarse grinding, middle grinding and fine grinding etc.

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.

Main Application
Resin bond grinding wheels have strong competitive advantages in the processing fields of carbide tools, ceramics, glass, PCBN tools, PDC cutter, Steel, cast iron, electronic information components precision cutting etc.

► OD cylindrical grinding wheel (1A1 shape)
► Diamond sanding belts
► Diamond internal grinding wheel
► Diamond honing stone
Model: 1A1 diamond wheel (diameter up to 1100mm)

Resin bond diamond & CBN wheels are mainly used for small-diameter tungsten, stainless steel or HSS drills, micro drills, and end mills used in electronics, medical technology, and the automotive industry.
Applications: face grinding, top grinding, flank grinding, hollow tooth grinding and re-sharpening for tungsten carbide tipped saw blades and one-piece HSS saws
Models: 4A2, 4BT9, 11A2, 15A2, 12V2, 14F1, etc

Used for machining HSS, tool steel, stainless steel, mold steel and titanium alloy etc。
Metal bond grinding wheel is made from the sintering of alloy powders and other fillers with either diamond grains or CBN grains. Compared to resin bond wheels, metal bond wheels provide longer using life and better shape retention。

Vitrified bond diamond grinding wheels have been widely used in the PCD/PCBN tools edge processing, diamond edge processing, carbide cylindrical processing and camshaft grinding and other processing fields. Vitrified bond grinding wheels will produce a lot of heat in the process of high load during dry grinding. Using the cooling fluid with vitrified grinding wheels the effect is more outstanding. The diameter range, the thickness range and the grit size range can be customerized according to customers’ requirement.

►Excellent Grinding Action
►less apt to experience loading, and they dress easily for added convenience
►Convenience and Ease of Use
►Grinding abilities apply to both wet and dry tasks on processing objects such as harden steel, glass, ceramic, carbide alloys, ferrite, refractories, semi conductors, and other electrical carbon products.

Usage:
1. Especially used for internal grinding of complex workpieces.
2. Used for dressing abrasive tools.
3. Used for processing industrial ceramics.
4. Suitable for processing and polishing cemented carbide, various molds, stone, glass, jade, gems, teeth, bones, high-speed steel and various high-hardness materials.

Moresuperhard provides resin diamond grinding wheels for the thermal spraying industry. Cylindrical diamond wheel is used for grinding and finishing of thermal spray coatings ( including tungsten carbide , chrome carbide and chrome oxide ), ceramics, carbides, chilled iron composites and other hard-to-grind materials.

■ Due to its self-sharpening, the resin bond wheel is easy to use and is suitable for roughing – finishing.
■ Due to moderate abrasive holding strength and wear resistance, this wheel is suitable for roughing with free cutting.
■ Due to elasticity, this wheel using fine grits is suitable for finishing.

5 axis cnc diamond grinding wheels are used for grinding carbide and HSS. (such as drill, end mill, reamer)
A complete solution for CNC tools manufacturing: fluting, gashing and Clear edge, relief angle grinding, OD grinding
Model of cnc wheels: 1A1, 1V1, 11V9, 12V9, 14A1, 12V5, etc

►Accurately grinding Tungsten Carbide, Ceramic, Cermet, Steel HRC, Glass and Others, etc.
►Diameter 20- Diameter 900, customized as your request
►CBN+aluminum body

Resin Bond CBN Grinding Wheel feature:
1）high efficiency；
2）abrasion resistance, high consumption
3）Small grinding force, grinding temperature is low
4）high accuracy and good surface quality of the workpiece, the shape of the workpiece stability is good
5）with more pores, grinding is good for chip removal and cooling, not easy to jam, and not easy to burn the workpiece
6）easy sharping
